描述
1. 9GL Series Technical Engineering Specifications
| 不。 | 物品 | 單元 | 規格 |
|---|---|---|---|
| 1 | 型號名稱 | / | 9GL-5.0/5.6 Towed Reciprocating Mower |
| 2 | 掛鉤類型 | / | Towed |
| 3 | Cutter Structure Type | / | Reciprocating |
| 4 | Cutting Width | 米 | 5 |
| 6 | Grass Cutting Working Width | 米 | 5.6 |
| 7 | Working Speed Range | 公里/小時 | 6~7 |
| 8 | 生產力 | 平方米/小時 | Forage: 2.4-2.8, Hay: 3.0-3.6 |
| 9 | Average Cutting Height | mm | 60-70 |
| 10 | Matching Power | 千瓦 | 30-60 |
| 11 | Power Output Shaft Speed | r/min | 540 |
| 12 | 機器重量 | 公斤 | 1100 |
| 13 | Number of Connectors | 件 | 78 |
| 14 | Hitch Distance | mm | 71 |
| 15 | Machine Dimensions (L × W × H) | mm | 3860 × 5600 × 3000 |
| 16 | Operating Condition | mm | 3860 × 7600 × 850 |
| 17 | Number of Moving Blades | 件 | 68 |
2. Technical Architecture and Material Science
The 9GL-5.0 and 9GL-5.6 series represent the next evolution in integrated hay management equipment, consolidating the mowing and raking processes into a single tractor pass. As a premier Mower/Raker manufacturer, we have optimized these trailed units to maximize hectares-per-hour productivity for professional forage growers. Utilizing high-precision reciprocating mower technology, these machines provide a surgical cut that protects the stem’s vascular structure, promoting faster regrowth compared to traditional rotary systems.
By eliminating the need for a separate raking operation, livestock cooperatives in regions like Gangwon-do and Jeju Island can reduce fuel consumption by up to 35% and minimize soil compaction—a critical factor for sustainable land management in South Korea. These models are engineered for tractors ranging from 45 to 80 HP, featuring a robust folding chassis that ensures a 5.0m to 5.6m working width in the field while maintaining a safe, compact transport profile on public roads.
3. Market Trend Analysis: The Future of Integrated Forage Management
The global agricultural machinery landscape is rapidly pivoting toward “Multifunctional Integration” and “Soil-Centric Productivity.” In South Korea, the rising cost of labor and the consolidation of small family plots into larger commercial cooperatives have driven a 20% annual increase in the demand for wide-swath, 2-in-1 implements like the 9GL series. We are seeing a significant move away from separate mowing and raking passes toward a single-operator “One-Pass” philosophy.
This trend is not only about saving time but also about maximizing the “harvest window.” In humid climates like the Korean summer, reducing the field drying time by even 24 hours can be the difference between Grade-A forage and moldy silage. Furthermore, as “Smart Farming” initiatives grow in South Korea, there is an increasing reliance on implements that offer uniform windrows, which are essential for automated baling systems and high-capacity forage harvesters.
4. Working Principle:
The 9GL-5.0/5.6 Towed Reciprocating Mower combines mowing and raking in one machine, which greatly enhances operational efficiency. The machine is designed to be towed by a tractor and uses reciprocating mower technology. This mechanism works by converting the tractor’s PTO (Power Take-Off) rotational power into linear motion through a precision crank-rod system. The two independent cutter bars (each 2.5 meters wide) are driven simultaneously, providing a combined cutting width of 5.0 meters to 5.6 meters.
Precision cutting: The reciprocating system offers a clean, shearing cut, which is more efficient than rotary systems, preserving the vascular structure of the grass and promoting faster regrowth.
No need for raking: By combining both mowing and raking functions, the mower collects and gathers the cut forage into windrows simultaneously, eliminating the need for a separate raking operation.
Fuel efficiency: This integration of mowing and raking reduces fuel consumption by up to 35%, making it more energy-efficient compared to using separate machines.
Soil preservation: The design minimizes soil compaction, which is crucial for sustainable farming, especially in regions like Gangwon-do and Jeju Island where the terrain can be uneven.
Wide compatibility: The mower is compatible with tractors in the 45–80 HP range, ensuring flexibility across various farming operations. The hydraulic folding chassis allows the machine to have a compact transport profile, which complies with road transport regulations in South Korea.
5. Global Success
Client 2 Profile: Agricultural Contractor, Jeju Island, South Korea
Client Testimonial:
“The heat-treated manganese steel blades are durable and wear-resistant, even when encountering rocks. The hydraulic folding system ensures we can safely transport the equipment between fields without worrying about width restrictions. The 5.0-meter cutting width allows us to efficiently handle large areas. All in all, it’s a high-quality product, and I will continue to use it in my contracting business.”
Client 3 Profile: Agricultural Cooperative, Pyeongchang, South Korea
Client Testimonial:
“The 9GL-5.6 mower has been a game-changer for our cooperative. We’ve switched from traditional separate mowing and raking equipment to this integrated solution, and we’ve noticed a huge improvement in operational efficiency. The machine is easy to operate, allowing us to harvest natural grass or cultivated pastures on small slopes without worrying about soil compaction. The cutting quality is excellent, and the machine’s productivity fully meets expectations. We’ve reduced fuel consumption and can now complete harvesting in half the time.”
Client 4 Profile: Dairy Farm Manager, Gangwon Province, South Korea
Client Testimonial:
“As a dairy farm manager, I need to ensure we provide the highest quality feed for our cows. The 9GL-5.0 mower helps us achieve this goal. The productivity range of 2.4-2.8 hectares/hour is perfect for our farm’s needs. With its efficient cutting and minimal impact on the soil, this mower is ideal for our terrain. The clean cut provided by the reciprocating cutting technology helps maintain the nutritional value of the feed, and we’ve noticed our hay dries more evenly, which significantly improves the quality of our silage. This is a must-have for any serious dairy farmer.”
6. EVER-POWER Factory: Customization & Quality Assurance
我們的生產基地位於呼倫貝爾經濟技術開發區，佔地超過 32,000平方米 該公司配備了最先進的數控雷射切割機、自動焊接生產線和靜電粉末噴塗生產線。我們不僅是組裝商，更是一家擁有深厚研發能力的綜合製造商。
客製化服務（OEM/ODM）： 我們了解不同地區的農業條件有差異。針對韓國市場，我們提供以下客製化選項：
• 水力適應： 調整閥門壓力以配合特定的 LS 或大同拖拉機液壓流量。
• 輪胎升級： 可選配更寬的浮力輪胎，適用於深泥稻田。
• 顏色與品牌： 為經銷商和分銷商提供OEM品牌推廣服務。
我們持有 ISO9001品質管理系統認證 公司已被認定為國家高新技術企業。每台9YG-2.24D打包機在出廠前都要經過嚴格的48小時連續運轉測試，以確保到貨時有零缺陷。
7. Related products
7.1 Gearbox:
相容型號：EP-FK263（方捆打捆機）、EP-RC30 系列（圓捆打捆機，傳動比 1:2，相容於 35mm 6 齒花鍵軸）。應用：將動力輸出軸 (PTO) 動力傳遞至打捆機構，適用於 New Holland 630 或 John Deere 535。參數：扭力 > 500 Nm，20% 節油。選擇此變速箱的理由：尺寸可客製化（可縮小至 250-300 毫米），耐黏性污染物（橡膠煙霧），IP65 防護等級。動力輸出軸：相容型號：EP-PTO 系列（1-3/8″ Z6 花鍵，可調長度 600-1200mm）。應用：連接曳引機和打捆機主驅動裝置，適用於9YG-1.0C型。扭力傳遞效率>95%，相容於SAE/EURO法蘭。適用理由：防水設計，適用於濕式青貯作業；可取代 Weasler 系列。
7.2 鏈條 鏈輪：
相容型號：ANSI 鏈條，附EP鏈輪（節距12.7-19.05mm，滾輪直徑10-12mm）。應用範圍：用於輸送帶或捆紮機構，適用於方捆/圓捆打捆機秸稈輸送。寬度25-40毫米，耐磨鋼材質。適用理由：與 Kobelco 或 HF 集團設備相容，降低鏈條斷裂風險；可提供食品級青貯飼料選項。
7.3 Couplings:
相容型號：EP-Coupling 200 系列（扭力匹配 500-1000 Nm）。應用：連接齒輪箱和打包輥，抑制振動。適用理由：高循環耐用性，相容於 Bondioli 和 Pavesi。
7.4 油壓缸:
液壓缸： EP-HC系列（缸徑50-100mm，行程300-600mm），適用於捆包提升。軸承和密封件：6208-2RS 軸承，L10 壽命 >10000 小時，防塵密封。相容性表格：與 Comer 250T 完全互換（扭矩匹配，價格僅為 35%）；法蘭與北美 4 螺栓 PTO 模式匹配。* 免責聲明：以上提及的其他品牌名稱僅供參考。我們不提供這些品牌名稱的原廠產品或設備。* 參數會因工作條件而異，請參考實際圖面。建議選型前確認介面尺寸。
8. Forage Harvesting Professional FAQ
Q1. What is the current commercial forage harvester price for the 5.6m trailed mower/rake delivered to Busan?
A1. The final investment for a 9GL-5.6 depends on your specific shipping logistics and customization needs. For commercial cooperatives in South Korea, we provide competitive high-capacity agricultural mower quotes that include international duties. Please click our “Get a Quote” button for a detailed commercial proposal within 24 hours.
Q2. Where can I find a reliable Trailed Mower/Rake supplier Korea that offers local maintenance support?
A2. We are a specialized industrial manufacturer with a dedicated export department serving the Korean agricultural sector. We partner with local technical service centers in Gyeonggi and Gangwon provinces to ensure your 9GL series receives genuine manganese steel spare parts and seasonal calibration.
Q3. How does the reciprocating mower technology benefit hay quality in humid Jeju Island pastures?
A3. Unlike rotary mowers that “beat” the grass, our reciprocating system uses a clean shearing cut. This preserves the plant’s moisture-conducting vessels, which allows the forage to dry more uniformly. In humid Jeju climates, this prevents internal fermentation and significantly improves the Grade-A haylage recovery rate.
Q4. What is the recommended tractor horsepower for pulling a 5.0m wide 9GL series mower/rake on hills?
A4. For optimal performance on sloped terrains typical of the Korean highlands, we recommend a tractor with at least 65 to 80 HP (48-58 kW). This ensures sufficient PTO torque to drive the 5.0m reciprocating cutter bar while maintaining steady towing stability at ground speeds of 5-8 km/h.
Q5. Are there specific Korea pasture harvesting regulations regarding the folding width of large agricultural implements?
A5. Yes, Korean regulations strictly limit the width of machinery on public agricultural roads. The 9GL-5.0/5.6 is designed with a high-clearance hydraulic folding system that brings its 5.6m working width down to a legal transport profile, allowing you to move between disconnected plots without special escort permits.
Q6. Which manganese steel alloy is used in your blades to resist stony volcanic soils in Jeju-do?
A6. We utilize a proprietary 65Mn heat-treated manganese alloy for all our reciprocating blades. This material is specifically chosen for its balanced hardness and fracture toughness, ensuring that even if the blade strikes a Jeju volcanic stone, it resists shattering and maintains a clean cutting edge.
Q7. How often should I inspect the reciprocating crank-rod system to maintain peak productivity?
A7. We recommend a daily visual inspection of the lubrication points during the harvest season. For every 100 operational hours, a thorough check of the drive belt tension and crank pin alignment is advised. This simple maintenance ensures the machine maintains its 4.5 hm²/h productivity rating for years.
Q8. Why should I choose an integrated mower-rake over two separate tractor-mounted implements?
A8. Choosing an integrated 9GL unit reduces your “Fuel-per-Hectare” cost by roughly 30%. More importantly, it halves the amount of heavy equipment passes on your pasture, which dramatically reduces soil compaction and promotes deeper root growth—a vital part of sustainable forage management equipment strategies.
Q9. Can your factory provide a high-capacity agricultural mower quote for custom tractor hitch standards used in Korea?
A9. Absolutely. While the 9GL series comes with a standard category 2 trailed hitch, we can customize the connection points to match specific LS Mtron or TYM tractor drawbar standards. We specialize in providing bespoke solutions that ensure a “Plug-and-Play” experience for your existing tractor fleet.
Q10. How does the 9GL-5.6 trailed mower/rake comply with South Korean land management construction laws?
A10. Under Korean MAFRA guidelines, agricultural machinery must minimize negative soil impact. Our 9GL series complies by utilizing high-flotation tires that spread the machine’s 1050 kg weight evenly. This prevents topsoil displacement and subsoil compaction, which is mandatory for maintaining soil fertility in permanent pasture zones.
